Four Pillar Full Head Presses (FH – 400 Tons)

Description

Features

Advantages

  • The Full Head series of die cutting machines were designed and engineered by European technicians with 50 years of experience.
  • The Full Head series has a strong exterior reinforced construction consisting of heavy duty weldments. This press is built for the long term which our customers expect.
  • This full head press uses a four column construction, and in the best and strongest American engineering tradition, utilizes an internal mechanical levelling system to insure a parallel cutting stroke and full uniform pressure all over the cutting bed, even when the cutting dies are not in the center of the cutting area. A parallel cutting stroke is essential for obtaining accurate cut parts and for long pad and die life. The most important fact is that the four pillar construction and internal mechanical levelling system keeps the bridge parallel far better than the common hydraulic levelling or straight arm systems used in some cutting machines.
  • Very efficient for making clean cuts of multiple layers of material
  • Simple to learn – Die height and material height can be reset in less than ten seconds with easy to use controls for setting die and material height which provides a fast set up time.
  • Low electrical power consumption which helps make the machine very quiet.
  • Low maintenance due to an automatic central lubricating system which continuously lubricates all of the main bushings and bearings.
Range of applications

These APMC Four Pillar Presses are excellent for diecutting:

  • Plastics
  • Foam
  • Leather
  • Gaskets
  • Felt
  • Abrasives
  • And many kinds of composites and textiles

Options

Machine Options
  • Double slide table- Allows for multiple operators to work at the same time and increase productivity from one single machine.
  • Pad Shifter- Mounts on the head of a full press machine and oscillates the polypropylene pad to reduce wear on die, as well as increase material yields.
  • Die Mounting rails- Allows for ease of access to die pads and makes changing die pads easier.
  • Wear Plate- Fitted to the slide table on the machine for through cutting of material upwards.
  • Material Feed Roller- Option automatically feed rolled material onto machine bed for quicker production time
  • Phase Converter- Option to switch the machine to run on single phase, 220V power.

Specifications

Cutting Force: 440 Tons (400 Metric Tons)
Cutting Stroke: 7.1" (180 mm) / 9.8" (250mm)
Maximum Daylight: 9.1" (230mm) / 11.8" (300mm) / (Others Available)
Machine Bed: (47.2-59" D x 59-98.4" W) / (1200-1500mm D x 1500-2500mm W)
Main Motor: 20 HP x 2
Gross Weight: TBD
Stroke: 4.3" (110 mm)
Series: FH - 400 Tons
