Automatic Sheet Edge Trimming and Sheet Splitting Machine (GC-700BSA)

Description

Designed specifically to cut and trim the two edges of a single sheet and split in halves.

Videos

Features

Features

The GC-700BSA is designed specifically to cut and trim the two edges of a single or double sheet. It can also split the double sheet into two single sheets. The driving devices use high-precision sensors to detect the printed registration marks to an accuracy of 0.1mm.

Advantages

Cross alignment sensors for both sheet axes ensure perferct trimming and splitting.
Multiple simultaneous operation (feeding, first edge trimming, second edge trimming) improves throughput.
Multiple program options allow any comibination of single or dual edge trimming and sheet splitting.
Touch screen controlled for easy program recall, changes and troubleshooting.
1,000 sheet capacity auto-loader that is hand-trolley accessible.

Options

Machine Options

Clean Roller between the sheet feeder and the first edge guillotine device
Touch Screen Operator Interface – The user friendly touch screen makes machine operation easy for any operator with the ability to store programs, recall programs, and change material specifications and feed distances all with the touch of a finger.
Material Loading – An individual sheet is picked up from the stack by vacuum suction pads and can be fed onto the inboard table for registration.
